SQUARE

• CRI 80

  věrnost podání barev

• interiérové svítidlo

• IP40

  krytí

• životnost 50 000 h

• bytové domy

• hotely

• kanceláře

• obchod

• školy

Filter		Wattage 3 W 6 W 12 W 18 W 24 W	Protection rating IP 40	Color temperature 3000 K 4000 K	Luminous flux 280 lm 550 lm 1100 lm 1700 lm 2300 lm	Color white silver	Equipment LED Driver On/Off Emergency module no value				filter reset
My selection	Ref. No.	Wattage	Protection rating	Color temperature	Luminous flux	Color	Equipment	Dimensions	LED Driver	Emergency module
	131-0399	3 W	IP 40	3000 K	280 lm	white	On/Off	85 x 85 x 21 mm	On/Off		Detail
	131-0398	3 W	IP 40	4000 K	280 lm	white	On/Off	85 x 85 x 21 mm	On/Off		Detail
	131-0401	6 W	IP 40	3000 K	550 lm	white	On/Off	120 x 120 x 21 mm	On/Off		Detail
	131-0400	6 W	IP 40	4000 K	550 lm	white	On/Off	120 x 120 x 21 mm	On/Off		Detail
	131-0403	12 W	IP 40	3000 K	1100 lm	white	On/Off	170 x 170 x 21 mm	On/Off		Detail
	131-0402	12 W	IP 40	4000 K	1100 lm	white	On/Off	170 x 170 x 21 mm	On/Off		Detail
	131-0405	18 W	IP 40	3000 K	1700 lm	white	On/Off	220 x 220 x 21 mm	On/Off		Detail
	131-0404	18 W	IP 40	4000 K	1700 lm	white	On/Off	220 x 220 x 21 mm	On/Off		Detail
	131-0169	24 W	IP 40	3000 K	2300 lm	white	On/Off	300 x 300 x 21 mm	On/Off		Detail
	131-0168	24 W	IP 40	4000 K	2300 lm	white	On/Off	300 x 300 x 21 mm	On/Off		Detail
	131-0171	3 W	IP 40	3000 K	280 lm	silver	On/Off	85 x 85 x 21 mm	On/Off		Detail
	131-0170	3 W	IP 40	4000 K	280 lm	silver	On/Off	85 x 85 x 21 mm	On/Off		Detail
	131-0407	6 W	IP 40	3000 K	550 lm	silver	On/Off	120 x 120 x 21 mm	On/Off		Detail
	131-0406	6 W	IP 40	4000 K	550 lm	silver	On/Off	120 x 120 x 21 mm	On/Off		Detail
	131-0409	12 W	IP 40	3000 K	1100 lm	silver	On/Off	170 x 170 x 21 mm	On/Off		Detail
	131-0408	12 W	IP 40	4000 K	1100 lm	silver	On/Off	170 x 170 x 21 mm	On/Off		Detail
	131-0411	18 W	IP 40	3000 K	1700 lm	silver	On/Off	220 x 220 x 21 mm	On/Off		Detail
	131-0410	18 W	IP 40	4000 K	1700 lm	silver	On/Off	220 x 220 x 21 mm	On/Off		Detail
	131-0173	24 W	IP 40	3000 K	2300 lm	silver	On/Off	300 x 300 x 21 mm	On/Off		Detail
	131-0172	24 W	IP 40	4000 K	2300 lm	silver	On/Off	300 x 300 x 21 mm	On/Off		Detail

Back to category

Download

Catalogue sheets square_data_sheet.pdf (pdf, 146.0 kB)

Declaration of conformity eu_dc_131-0399.pdf (pdf, 62.5 kB)

Mounting instructions square_manual.pdf (pdf, 537.4 kB)
